SMCJ5629表面貼裝TVS二極管Microsemi
發布時間：2024-12-04 09:03:22 瀏覽：276
Microsemi 的 SMCG5629 至 SMCG5665A 和 SMCJ5629 至 SMCJ5665A
是一系列表面貼裝的瞬態電壓抑制器(TVS)，主要用于保護對低鉗位電壓水平敏感的組件。
產品描述
用途：保護對電壓敏感的組件，適用于高電流脈沖，通常由感性開關瞬變產生。
特點：低輪廓表面貼裝J型或鷗翼型端子，有助于減輕應力和降低重量。與其他MELF風格封裝相比，低平輪廓提供了更容易的插入或自動處理優勢。
篩選選項：提供類似于JAN, JANTX, JANTXV, 和 JANS的篩選選項，通過使用MQ, MX, MV 或
MSP作為部件編號前綴，并根據MIL-PRF-19500/507進行高可靠性篩選。
產品特點
工作獨立電壓：5.5V至171V。
金屬鍵合：確保了產品的可靠性。
可靠性數據：符合JESD22-A108, JESD22-A104, JESD22-A113-B, JESD22-A101-B, 和
JESD22-A102標準。
熱效率高：表面貼裝具有J型或鷗翼型端子，用于應力緩解(平面處理表面和更容易放置)。
最大額定值
工作溫度：-55°C至+150°C。
存儲溫度：-55°C至+150°C。
峰值脈沖功率：1500W(10/1000微秒)。
熱阻：20°C/W。
脈沖重復率：0.01%。
穩態最大功率：5.0W(在25°C時)。
鉗位時間：最大50皮秒(理論值)。
正向電壓：在100安培8.3毫秒時最大3.5V。
應用/優勢
高可靠性：適用于低輪廓表面貼裝位置，易于放置和緩解應力。
輕量化：適用于航空或衛星應用。
浪涌保護：符合IEC61000-4-2和-4-4標準，保護ESD和EFT瞬變。
防雷保護：符合IEC61000-4-5標準，適用于Class 1和2，以及在較低電壓和較高浪涌電流等級下的Class 3和4。
保護敏感組件：如ICs, CMOS, Bipolar, BiCMOS, ECL, DTL, T2L等。
型號參數：
| ELECTRICAL CHARACTERISTICS @25℃(Test Both Polarities) |
MICROSEM
Part Number
Modified
-G
Bend Lead | MICROSEM
Part Number
Modified
Bend Lead | Breakdown
Voltage*
(VsR)
MIN.MAX |
Test
Current
(aR) | Rated
Standoff
Voltage
(Vwm) | Maximun
Standby
Current
(o at Mwm) |
Maximum Peak
Reverse Voltage
(Ve max.at Ipe) |
Maximum Peak
Pulse Current
pp |
| Vdc | Vdc | mAdc | V | μAdc | V | A |
SMCG5629
SMCG5629A
SMCG5630
SMCG5630A | SMCJ5629
SMCJ5629A
SMCJ5630
SMCJ5630A | 6.12
6.45
6.75
7.13 | 7.48
7.14
8.25
7.88 | 10
10
10
10 | 5.50
5.80
6.05
6.40 | 1000
1000
500 500 | 10.8
10.5
11.7
11.3 | 39
143
128
132 |
SMCG5631
SMCG5631A
SMCG5632
SMCG5632A | SMCJ5631
SMCJ5631A
SMCJ5632
SMCJ5632A | 7.38
7.79
8.19
8.65 | 9.02
8.61
10.0
9.55 | 10
10 1 1 | 6.63
7.02
7.37
7.78 |
200
200 50 50 | 12.5
12.1
13.8
13.4 | 120
124
109
112 |
SMCG5633
SMCG5633A
SMCG5634
SMCG5634A | SMCJ5633
SMCJ5633A
SMCJ5634
SMCJ5634A | 9.00
9.5
9.9
10.5 | 11.0
10.5
12.1
11.6 | 1 1 1 1 | 8.10
8.55
8.92
9.40 | 10
10
5
5 | 15.0
14.5
16
15.6 | 100
03
93
96 |
SMCG5635
SMCG5635A
SMCG5636
SMCG5636A | 3MCJ5635
SMCJ5635A
SMCJ5636
SMCJ5636A | 10.8
11.4
11.7
12.4 | 13.2
12.6
14.3
13.7 | 1 1 1 1 | 9.72
10.2
10.5
11.1 | 5 5 5 5 | 17.3
16.7
19.0
18.2 | 87
90
79
82 |
SMCG5637
SMCG5637A
SMCG5638
SMCG5638A | SMCJ5637
SMCJ5637A
sMCJ5638
SMCJ5638A | 13.5
14.3
14.4
15.2 | 16.5
15.8
17.6
16.8 | 1 1 1 1 | 12.
12.8
12.9
13.6 | 5 5 5 5 | 22.0
21.2
23
22.5 | 68
71
64
67 |
SMCG5639
SMCG5639A
SMCG5640
SMCG5640A | SMCJ5639
SMCJ5639A
SMCJ5640
SMCJ5640A | 16.2
17.1
18.0
19.0 | 19.8
18.9
22.0
21.0 | 1 1 1 1 | 14.5
15.3
16.2
17.1 | 5 5 5 5 | 26
25 2
29.1
27.7 | 56.5
51.5
54 |
SMCG5641
SMCG5641A
SMCG5642
SMCG5642A | SMCJ5641
sMCJ5641A
SMCJ5642
SMCJ5642A | 19.8
20.9
21.6
22.8 | 24.2
23.1
26.4
25.2 | 1 1 1 1 | 17.8
18.8
19.4
20.5 | 5 5 5 5 | 31.9
30.6
34.7
33.2 | 47
49
43
45 |
SMCG5643
SMCG5643A
SMCG5644
SMCG5644A | SMCJ5643
SMCJ5643A
SMCJ5644
SMCJ5644A | 24.3
25.7
27.0
28.5 | 29.7
28.4
33.0
31.5 | 1 1 1 1 | 21.8
23.1
24.3
25.6 | 5 5 5 5 | 39.1
37.5
43.5
41.4 | 385
40
34.5
36 |
SMCG5645
SMCG5645A
SMCG5646
SMCG5646A | SMCJ5645
SMCJ5645A
SMCJ5646
SMCJ5646A | 29.7
31.4
32.4
34.2 | 36.3
34.7
39.6
37.8 | 1 1 1 1 | 26.8
28.2
29.1
30.8 | 5 5 5 5 | 47.7
45.7
52.0
49.9 | 31.5
33
29
30 |
SMCG5647
SMCG5647A
sMCG5648
SMCG5648A | SMCJ5647
SMCU5647A
MCJ5648
SMCJ5648A | 35.1
37.1
38.7
40.9 | 42.9
41.0
47.3
45.2 | 1 1 1 1 | 31.6
33.3
34.8
36.8 | 5 5 5 5 | 56.4
53.9
61.9
59.3 | 26.5
28
24
25.3 |
SMCG5649
SMCG5649A
SMCG5650
SMCG5650A | SMCJ5649
SMCJ5649A
BMCJ5650
SMCJ5650A | 42.3
44.7
45.9
48.5 | 51.7
49.4
56.1
53.6 | 1 1 1 1 | 38.1
40.2
41.3
43.6 | 5 5 5 5 | 67.8
64.8
73.5
70.1 | 22.2
23.2
20.4
21.4 |
SMCG5651
ChcG56514
SMCG5652
SMCG5652A | SMCJ5651
SMCJ5651A
SMCJ5652
SMCJ5652A | 50.4
53.2
55.8
58.9 | 61.6
58.8
68.2
65.1 | 1 1 1 1 | 45.4
47.8
50.2
53.0 | 5 5 5 5 | 80.5
77.0
39.0
85.0 | 18.6
19.5
16.9
17.7 |
SMCG5653
SMCG5653A
SMCG5654
SMCG5654A | SMCJ5653
SMCJ5653A
SMCJ5654
SMCJ5654A | 61.2
64.6
67.5
71.3 | 74.8
/1.4
82.5
78.8 | 1 1 1 1 | 55.1
58.1
60.7
64.1 | 5 5 5 5 | 98.0
92.0
108
103 | 15.3
16.3
13.9
14.6 |
SMCG5655
SMCG5655A
SMCG5656
SMCG5656A | SMCJ5655
BMCJ5655A
SMCJ5656
SMCJ5656A | 73.8
77.9
81.9
86.5 | 90.2
86.1
100.0
95.5 | 1 1 1 1 | 66.4
70.1
73.7
77.8 | 5 5 5 5 | 118
113
131
125 | 12.7
13.3
11.4
12.0 |
SMCG5657
SMCG5657A
SMCG5658
SMCG5 658A | sMCJ5657
SMCJ5657A
SMCJ5658
SMCJ5658A | 90
95
99
105 | 110
105
121
116 | 1 1 1 1 | 81.0
85.5
89.2
94.0 | 5 5 5 5 | 144
137
158
152 | 10.4
11.0
9.5
9.9 |
SMCG5659
SMCG5659A
SMCG5660
SMCG5660A | SMCJ5659
SMCJ5659A
SMCJ5660
SMCJ5660A | 108
114
124 | 132
126
143
137 | 1 1 1 1 | 97.2
105
111 | 5 5 5 5 | 173
187
179 | 8.7
9.1
8.0
8.4 |
SMCG5661
SMCG5661A
SMCG5662
SMCG5662A | SMCJ5661
SMCJ5661A
BMCJ5662
SMCJ566 2A | 135
143
152 | 165
158
176
168 | 1 1 1 1 | 121
128
130
136 | 5 5 5 5 | 215
207
230
219 | 7.0
7.2
6.5
6.8 |
SMCG5663
SMCG5663A
SMCG5664
SMCG5664A | BMCJ5663
SMCJ5663A
sMCJ5664
SMCJ5664A | 53
162
71 | 187
179
198
189 | 1 1 1 1 | 138
145
146
154 | 5 5 5 5 | 244
234
258
246 | 6.2
6.4
5.8
6.1 |
SMCG5665
SMCG5665A | CJ566
SMCJ5665A | 180
190 | 220
210 | 1 1 | 62
171 | 5 5 | 287
274 | 5.2
5.5 |
